LAUNCH CR529 OBD2 Scanner OBD Code Reader Car Diagnostic Tool

LAUNCH CR529 OBD2 Scanner OBD Code Reader Car Diagnostic Tool

Functions of LAUNCH CR529

1. Read, Clear engine error codes.

Turn off ‘Engine Check’ MIL.

2. Live Data / Freeze Frame

— When emission-related faults occur, certain vehicle conditions are recorded to locate the abnormality’s abnormal position better and cause when it is repaired.

3.I/M Readiness

— It indicates whether or not the various emissions-related systems on the vehicle are operating properly and are ready for Inspection and Maintenance testing.

4. VIN Code Reading Automatically

It can be reading the VIN code from the car ECU automatically.

5.Hard(memory) Codes Reading

6. Pending Codes Reading

7. Oxygen Sensor Test

CR529 allows retrieval and viewing of O2 sensor monitor test results for the most recently performed tests from the vehicle’s onboard computer.

8. On-Board Monitor

It allows you to view the results of On-Board Monitor tests. After servicing or erasing a vehicle’s control module memory, the tests are useful.

9. Vehicle Information:

The option displays the vehicle identification number (VIN), the calibration identification, the calibration verification number (CVN), and other information about the test vehicle.

Supported Languages:

English, French, Spanish, German, Portuguese, Russian, and Japanese.

Car Coverage

LAUNCH CR529 is compatible with most worldwide models manufactured as from 1996, with the support of all OBDII protocols: KWP2000, ISO9141, J1850 VPW, J1850 PWM and CAN (Controller Area Network).

Other Features

1. Record & Replay

Record all issues while doing the diagnostic work, and you can later on check the records related wherever, whenever.

2. HELP Shortcut Key

Comfortably help you to resolve most basic issues in a second with tips.

3. LED Indicator

Quick and easy way to identify your vehicle’s status visually, via its Green, Yellow and Red LED light.

4. Print Via Computer

You can connect it to your computer and print the diagnositc report.

5. Update Via Computer

You can connect to your computer and update it via Internet.

(1). Download the upgrade tool of the product: https://eninfo.x431.com/prod_view.aspx?TypeId=68&Id=323&FId=t3:68:3

(2). After installation, connect the scanner to the computer.

(3). Once the tool is powered up, launch the update tool on your computer, the system starts reading the tool. Once it obtains the tool information, click [Device Upgrade], a registration window will pop up.

(4). Fill in the required information and click[Submit] to navigate directly to the update center.

(5). Click [Upgrade] to start updating until the update is complete.
